Shuttle Intel Celeron 3865U, max. DDR4-2133 SoDIMM, touch, Intel HD Graphics 610, Gigabit LAN, WLAN, Bluetoo

Intel Celeron 3865U
Ratings
Currently out of stock
Free shipping starting at 50.–

Product details

The Shuttle XPC P90U is a powerful all-in-one barebone PC specifically designed for use in POS, POI, and kiosk applications. Featuring a 19.5-inch capacitive touchscreen, it provides a user-friendly interface that allows for intuitive operation. Powered by an Intel Celeron 3865U processor, this barebone PC combines high computing power with low energy consumption. The fanless design ensures nearly silent operation and minimizes maintenance efforts, making it ideal for 24/7 continuous use. The IP54 certification guarantees that the device is protected against dust and splashes, making it particularly robust for use in demanding environments. The arrangement of ports on the underside of the case enhances usability and allows for a clean installation.

  • Fanless design for silent operation
  • IP54 certified for dust and splash protection
  • Ideal for 24/7 continuous operation
  • Capacitive touchscreen for intuitive operation
  • Expandable connectivity with PCI Express and USB ports.

Key specifications

Number of processor cores
2 -Core
Graphics card model
HD Graphics 610
Internal connection options
PCI Express x4 (1x)
Network connections
RJ45 (1x)
Video connections
HDMI (1x)
Memory type
DDR4-RAM
USB ports
USB-A
Item number
17524462

General information

Manufacturer
Shuttle
Category
Barebones
Manufacturer no.
PAB-P90U002
Release date
19.11.2021

Barebone properties

Design
All-in-one

Processor

Processor type
Intel Celeron 3865U
Clock frequency
1.80 GHz
Number of processors
1 x
Number of processor cores
2 -Core
Number of threads
2
Socket
BGA 1356
Max. turbo clock rate
1.80 GHz
Max. TDP
15 W

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Max. memory slots
2
Max. RAM
32 GB
Memory voltage
1.20 V

Graphics card properties

Graphics card model
HD Graphics 610

Internal connections

Internal connection options
PCI Express x4 (1x)
Data storage controller
Intel SoC

External connections

USB ports
USB-A
Exact USB ports
USB-A 3.0 (2x)
Data ports
PS/2 (4x)

Network

Network connections
RJ45 (1x)
Max. port speed
1000 Mbit/s

Wireless transmission

Connectivity
Bluetooth, WLAN
Wi-Fi standard
Wi-Fi 5 / 802.11ac
Bluetooth version
4.1

Video connections

Video connections
HDMI (1x)

Audio connections

Audio outputs
6.3mm stereo (1x)

Card reader properties

Memory card type
SD, SDHC, SDXC

Power supply properties

Power
65 W

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Quickstart overview

Product dimensions

Weight
4290 g
Width
487 mm
Length
44 mm
Height
321 mm
