Shuttle Barebone AIO P15WL01-i5 15.6" i5-8365UE White
Intel Core i5-8365UEProduct details
The P15WL01-i5 is a high-quality panel PC featuring a robust aluminum housing with an IP65-compliant front. It is powered by an Intel Core i5 ULV processor and has a Full HD display with projected capacitive 10-point multitouch functionality. Thanks to its passive cooling system, the device operates virtually silently, requires no maintenance, and is approved for 24/7 continuous operation. This makes it ideal for rugged and public applications such as healthcare, hospitality, digital signage, points of information, point of sale, kiosks, and industrial use.
Graphics card model | UHD Graphics 620 |
Memory type | DDR4-RAM |
Video connections | HDMI (1x) |
Network connections | RJ45 (2x) |
USB ports | USB-A |
Number of processor cores | 4 -Core |
Item number | 37021509 |
Manufacturer | Shuttle |
Category | Barebones |
Manufacturer no. | P15WL01-I5 |
Release date | 11.7.2023 |
Design | All-in-one |
Processor type | Intel Core i5-8365UE |
Clock frequency | 1.60 GHz |
Number of processors | 1x |
Number of processor cores | 4 -Core |
Number of threads | 16 |
Max. turbo clock rate | 4.10 GHz |
Max. TDP | 15 W |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Max. memory slots | 2 |
Max. RAM | 64 GB |
Memory voltage | 1.20 V |
Graphics card model | UHD Graphics 620 |
Data storage controller | Intel SoC |
USB ports | USB-A |
Exact USB ports | USB-A 2.0 (4x), USB-A 3.2 Gen 1 (4x) |
Data ports | PS/2 (4x) |
Network connections | RJ45 (2x) |
Max. port speed | 1000 Mbit/s |
Connectivity | Bluetooth, WLAN |
Wi-Fi standard | Wi-Fi 5 / 802.11ac |
Bluetooth version | 4.2 |
Video connections | HDMI (1x) |
Audio outputs | Headphones Out (1x) |
Power | 90 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | VESA bracket |
Weight | 4600 g |
Width | 394.30 mm |
Length | 48.90 mm |
Height | 256.20 mm |
