Product details
High performance and great reliability in this new line of small form factor and modern FOCUS+ Gold power supplies are a guarantee for many years of undisturbed and problem-free usage. The FOCUS+ Gold
750 watt power supplies meet the latest ATX and EPS standards and are ready to be sued with any of the state-of-the-art Intel Core i7 Processors. All FOCUS+ Gold products come equipped with a wide range of safety and protection features to safeguard the system components in critical situations and they have the official approvals of the most important safety agencies.
80 PLUSGold
Seasonic was the forerunner of creating the very first 80 PLUS Gold certified power supply on the market and since that time it has built a very popular Gold series lineup that covers a full power range of power supplies with impeccable performance and efficiency. The highly efficient 80 PLUS Gold certification guarantees greater than 87 %, 90 % and 87 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. The clear advantage of buying a power supply with 80 PLUS Gold rating is the fact that the less energy gets wasted during power conversion, the lower the operating costs will be for the user.
Compact Size
This ultra-high power density, small footprint (140 mm depth) power supply is an ideal choice for all, especially compact ATX cases.
Fluid Dynamic Fan Bearing
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.
80 PLUSGold
Seasonic was the forerunner of creating the very first 80 PLUS Gold certified power supply on the market and since that time it has built a very popular Gold series lineup that covers a full power range of power supplies with impeccable performance and efficiency. The highly efficient 80 PLUS Gold certification guarantees greater than 87 %, 90 % and 87 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. The clear advantage of buying a power supply with 80 PLUS Gold rating is the fact that the less energy gets wasted during power conversion, the lower the operating costs will be for the user.
Compact Size
This ultra-high power density, small footprint (140 mm depth) power supply is an ideal choice for all, especially compact ATX cases.
Fluid Dynamic Fan Bearing
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.
| Form factor | ATX |
| 80 PLUS certificate | Gold |
| Modularity | Modular cable management |
| Internal connection options | 15-pin S-ATA (8x), 20+4 PIN ATX power connector (1x), 4-pin floppy (1x), 4-pin Molex (3x), 4+4-pin 12V (2x), 6+2-pin PCI Express (4x) |
| Documents | |
| Item number | 6392505 |
| Manufacturer | |
| Category | |
| Manufacturer no. | SSR-750FX |
| Release date | 7/9/2017 |
| Colour group | Black |
| Exact colour description | Black |
| Form factor | ATX |
| 80 PLUS certificate | Gold |
| Modularity | Modular cable management |
| Internal connection options | 15-pin S-ATA (8x), 20+4 PIN ATX power connector (1x), 4-pin floppy (1x), 4-pin Molex (3x), 4+4-pin 12V (2x), 6+2-pin PCI Express (4x) |
| Cooling method | Active cooling |
| Number of fans | 1 x |
| Fan diameter | 120 mm |
| Power protection features | EIA, OCP, OPP, OTP, OVP, SCP |
| Power | 750 W |
| Sustainability | Energy-efficient use |
| Label | Energystar |
| Length | 14 cm |
| Width | 15 cm |
| Height | 8.60 cm |
| Length | 31.50 cm |
| Width | 12 cm |
| Height | 18.50 cm |
| Weight | 2.84 kg |
Specifications may include unverified machine translations.
