Schneider GmbH Pull switch insert pearl white 735100

Elso Pull Switch Insert 735100

Manufacturer: Elso
Description: Pull switch insert pearl white
Type: 735100
Composition: Base element
Operation: Pull cord
Design: Wall device
Suitable for: Call
Color: Other
Material: Other
Material quality: Other
Bus capable: 2-wire
Type of power supply: External
Switch function: Trigger call
With connection for: Other
Min. depth of device box: 46 mm

Additional details: Call button with system socket for comfort push button for Elso Scala/Fashion/Riva, color: pearl white, connection for comfort push button with and without light button, address-coded max. 6 buttons/room possible, integrated calming lamp, two outputs for switching external loads: max. 24 VDC 0.2 A cos(Phi) 1, connection to room bus, power supply: 24 VDC, current consumption: max. 30 mA, installation: flush-mounted box/surface-mounted frame.
