Schneider Electric Pushbutton housing 22mm 1 hole grey

Series: Harmony XALD
Cutout diameter: 22mm
Number of mounting points: 1
Housing color: Gray
Housing marking: None
Housing material: Plastic
Protection class: IP66, IP67, IP69, IP69K
Length: 68mm
Width: 68mm
Depth: 53mm
Operating temperature max.: +70°C
Operating temperature min.: -40°C
Dimensions: 68 x 68 x 53mm

UL, CSA, CE marking, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 4520. The XAL pushbutton enclosure is designed for Harmony® 5 switches, 22 mm. Schneider's Harmony XAL series is an empty enclosure for use with plastic pushbuttons, annunciators, selector switches, mushroom head actuators, legend plates, and XB5 series accessories. Suitable for normal environments, it has CSA and UL approval. The polycarbonate enclosure features a light gray color with either a dark gray or yellow cover and includes stainless steel cover mounting screws.
