Schneider Electric Circuit breaker NG125N, 2P, 63A, C- 18628

Ratings
Delivered between Tue, 29.7. and Sat, 16.8.

Product details

Acti 9 NG125N circuit-breaker, 25kA (IEC/EN 60947-2). 1-pole, rated current 63A, C characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 690V AC. Circuit protection against short-circuit currents. Protection of the circuit against overload currents. Tripping is indicated by the centre position of the switching toggle and by a red mechanical indicator on the front of the device. Test button for checking the tripping mechanism. Feed from above or below. Snap action for low-wear switching of the contacts. Release unit technology - thermomagnetic. Additional stackable auxiliary modules (optional)- indication of switching position, fault tripping, shunt opening release, undervoltage release, overvoltage release. The NG125N circuit-breaker fulfils the following standards- IEC/EN 60947-2. Furthermore, this series is VDE certified.

Key specifications

Circuit breaker type
Circuit breaker
Width
3 mm
mounting style
Top-hat rail
number of poles
2
Item number
23347873

General information

Manufacturer
Schneider Electric
Category
Residual-current device
Manufacturer no.
18628
Release date
7.12.2022

Circuit Breaker Features

Circuit breaker type
Circuit breaker
mounting style
Top-hat rail
number of poles
2
Tripping characteristic
C
Rated current
63 A
Rated voltage
400 V
voltage type
AC/DC
Rated insulation voltage Ui
690 V
Protection type (IP code)
IP20

Origin

Country of origin
France

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Schneider Electric fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Width
3 mm

30-day right of return if unopenedReturn policy
24 Months Warranty (Bring-in)Warranty provisions
