Schlegel FRVKDOO AU Active illuminated safe emergency stop button with status display active/inactive 2Ö

Schlegel active-luminous safe emergency stop button with active/inactive status indicator
Series: SHORTRON®
Installation opening: Ø 22.3 mm
Installation depth: 25 mm
Protection class: IP65 / IP67
Illumination: yes
Can be labelled: no
Contact type: 2NC
Connection type: blade terminal 2.8 mm x 0.8 mm
Front frame: yellow
Mushroom button: red
Storage temperature: -40°C ... 80°C
Positive opening: according to EN60947-5-1, Annex K
Operating temperature: -25°C ... 70°C
Mechanical service life: 50000
Shape: round
Electrical service life: 50000 at rated load
Overload protection: yes
Blocking protection collar: no
Switch position indicator: yes
Unlocking: clockwise and anti-clockwise rotation
Contact material: AgNi
Standards: ISO 13850:2015(E), EN ISO 13850:2015(D), DIN EN ISO 13850:2016-05
Supplied without external LED monitoring LED: 24V DC/18mA.
