Savöx Standard Servo SC-1268SG+ 25 kg Digital HV

The SC-1268SG+ is a powerful standard-sized servo that is well-suited for use as a steering or throttle servo in buggies or truggies. Of course, it can also be used in airplanes when a durable, impact-resistant servo is required, such as for tow couplings or landing gear. Another option is its application as a swashplate servo for scale helicopters up to the 700 class. The new + version of the well-known SC-1268SG+ servo differs only minimally in appearance and technology from its predecessor. A soft start feature, which slowly moves the servo to its starting position when powered on, and the Sanwa SSR mode are highlights of the + version. The technical specifications of the servo leave nothing to be desired: 0.11/0.10 sec/60 degrees and 25/30 kg*cm at 7.4/8.4 volts, with a control frequency of up to 333 Hz and a center pulse of 1520 µs. Like all HV servos from Savöx, the SC-1268SG+ can naturally be operated with up to 8.4 V.
