Samsung 860 Evo

500 GB, M.2 2280
Currently out of stock
Free shipping starting at 50.–

Product details

The Samsung 860 EVO is aimed at demanding private users who want to enhance the performance of their PCs or notebooks. It utilizes TLC V-NAND with 64 layers of memory. Thanks to the Intelligent TurboWrite technology with a variable SLC buffer, it achieves higher performance over longer periods compared to current TurboWrite technologies. Benefit from maximum compatibility and stability: originally designed for data center SSDs, the new MJX controller processes data faster, performs finer error corrections, and supports larger drive capacities. In terms of reliability, the 860 EVO has been significantly improved, achieving up to 8 times higher TBW (Terabytes Written) values than its predecessor. The 860 EVO is equipped with the latest hardware-based disk encryption engine. The AES 256-bit and TCG Opal 2.0 encryption secure data without compromising performance. It is also compatible with IEEE-1667 for Microsoft's eDrive. You can rest easy knowing that your data is protected at all times. M.2 SSDs are installed via the M.2 socket on the motherboard. This SSD transfers data using SATA III, making its compact size a major advantage. M.2 SSDs are particularly suitable for use in ultrabooks and mini-PCs due to their compact dimensions, but they can also be used in standard computers.

Key specifications

SSD type
M.2 SSD
Interface
SATA III
Protocol
AHCI (SATA)
Write transfer speed
500 MB/s
Read transfer speed
540 MB/s
Max. random 4K read
98000 IOPS
Max. random 4K write
90000 IOPS
Item number
7197989

General information

Manufacturer
Samsung
Category
SSD
Manufacturer no.
MZ-N6E500BW
Release date
11.12.2017
External links

Data storage properties

SSD type
M.2 SSD
Form factor
M.2 2280
Storage capacity
500 GB
Interface
SATA III
Protocol
AHCI (SATA)
Read transfer speed
540 MB/s
Write transfer speed
500 MB/s
Memory type (NAND)
TLC
Max. random 4K read
98000 IOPS
Max. random 4K write
90000 IOPS
Max. TBW
300 TB
Storage Cooling
without heatsink
SSD Features
AES encryptionSMART SupportSSD TRIM Support

Power supply

Power consumption (standby)
0.50 W
Power consumption
4.70 W

Sustainability

Manufacturer commitment
RE100

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Samsung fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Instruction manual

Product dimensions

Length
8 cm
Width
2.20 cm
Height
2.21 cm
Weight
7 g

Package dimensions

Length
14.20 cm
Width
10 cm
Height
2.20 cm
Weight
74 g
