RS PRO 72way header,14.7mm,2.9mm,size7

Grid = 2.54mm
Number of contacts = 72
Number of rows = 2
Housing orientation = Straight
Matching pin length = 14.5mm
Mounting type = Thru-hole
Termination type = Solder
Contact coating = Bright tin
Rated current = 4A

RS pin header connectors for PCB mounting without jacketing with 2.54 mm pitch and square pins. A series of pin header connectors for PCB mounting without jacketing with 0.635 mm square pins and 2.54 mm pitch. These 2.54 mm male connectors for PCB mounting without jacketing are available in single row 36-pin or double row 72-pin versions with a variety of pin heights and PCB contact lengths. The housings of these 2.54 mm PCB mount headers without jackets are made of black, fiberglass-reinforced PBT conforming to UL94V-0, and the contacts are bright tin-plated. Various pin heights and lengths of PCB solder tag Can be separated to desired length.
