Server-capable Intel Xeon E processor and ECC memory for high performance and reliability.
The Intel Xeon E-based TS-883XU enterprise NAS, with up to 64 GB DDR4 ECC (Error Correcting Code) memory, delivers server-level performance with high reliability. It features 10GbE SmartNIC controllers that not only meet bandwidth-intensive applications but also support iSER to offload CPU workloads with enhanced virtualization performance, while PCIe expansion allows for the installation of graphics cards to support video surveillance, virtualization, and AI applications. The performance-oriented TS-883XU offers advanced, enterprise-ready features, including software-defined SSD extra overprovisioning, software-defined networking, virtual switch, and much more.
The DDR4 ECC memory detects and corrects single-bit memory errors, providing high reliability for critical applications.
Two 10GbE SFP+ SmartNIC ports with iSER support accelerate the sharing of large files, intensive data transfers, and VMware virtualization applications.
PCIe expandability allows for graphics cards or 40GbE/25GbE/10GbE adapters to enhance application performance.
Supports virtualization with VMware, Citrix, Microsoft Hyper-V, and Windows Server 2016 with a high degree of reliability and cost efficiency.
Software-defined SSD extra overprovisioning combats write amplification and optimizes SSD write speeds for IOPS applications.
Comprehensive security management that provides a security portal for your NAS, helping you stay informed about the NAS status at all times.
Max. number of hard disks | 8 |
Memory | 8 GB |
NAS HDD assembly | NAS Empty Enclosure |
Total storage capacity | 0 TB |
RAID configuration | 0, 1, 10, 5, 50, 6, 60, JBOD |
Network connections | RJ45 (4x) |
Documents | |
Item number | 10274422 |
Manufacturer | QNAP |
Category | NAS |
Manufacturer no. | TS-883XU-E2124-8G |
Release date | 8.11.2018 |
External links |
Colour | Black |
Exact colour description | Black |
NAS HDD assembly | NAS Empty Enclosure |
Model | 19" rack |
Rack Unit | 2U |
Max. number of hard disks | 8 |
RAID configuration | 0, 1, 10, 5, 50, 6, 60, JBOD |
Memory type | DDR4-RAM |
Memory | 8 GB |
Maximum possible memory | 128 GB |
Data storage configuration | 0 TB |
Total storage capacity | 0 TB |
Hard disk additional functions | Hot swapping |
Processor type | Intel Xeon E-2124 |
Clock frequency | 3.30 GHz |
Max. turbo clock rate | 4.30 GHz |
Number of processor cores | 4 -Core |
Network connections | RJ45 (4x) |
Connectivity | USB |
Internal connection options | PCI Express x16 (1x), PCI Express x8 (2x) |
Power consumption | 72.16 W |
Fan diameter | 60 mm |
CO₂-Emission | |
Climate contribution |
Scope of delivery | AC Cables, RJ-45 Cable |
Length | 56.20 cm |
Width | 48.20 cm |
Height | 8.83 cm |
Weight | 10.40 kg |
