QNAP ES1686dc-2123IT-64G

0 TB
Ratings
BrandMore from QNAP
Currently out of stock
free shipping

Random access memory (RAM)2

Product details

To ensure high availability for businesses, the ES1686dc Enterprise ZFS-NAS features Intel Xeon D processors, two active controllers, up to 512 GB of DDR4 ECC memory, SAS 12Gb/s, and ZFS, which supports the management of logical drives. The ES1686dc runs the latest QES 2.1.0 operating system, which supports nearly unlimited snapshots, SnapSync, block-level data deduplication, and inline data compression. Whether used as a business-critical file server, virtualization server, VDI, mid-sized data center, video streaming, surveillance storage, or efficient file backup and recovery, the ES1686dc helps your business meet service level agreements for performance and uptime.

Active-active high availability with optimal storage efficiency. In the active-active storage system architecture, both controllers are capable of providing a full range of services, differing from the active-standby architecture.

Key specifications

NAS HDD assembly
NAS Empty Enclosure
Max. number of hard disks
16
RAID configuration
0, 1, 10, 5, 50, 6, 60
Working memory
64 GB
Total storage capacity
0 TB
Network connections
RJ45 (3x)
Exact USB ports
USB-A 3.2 Gen 1 (2x)
Documents

General information

Item number
12933260
Manufacturer
QNAP
Category
NAS
Manufacturer no.
ES1686DC-2123IT-64G
Release date
17.3.2020

Colour

Colour
Black, Grey
Exact colour description
Black, Gray

NAS properties

NAS HDD assembly
NAS Empty Enclosure
Model
19" rack
Rack height units
3 U
Max. number of hard disks
16
Hard drive form factor
2.5" (with optional mounting), 3.5"
RAID configuration
0, 1, 10, 5, 50, 6, 60
Working memory
64 GB
Maximum possible memory
512 GB

Hard drive slots

Data storage configuration
0 TB
Total storage capacity
0 TB

Processor

Processor type
Intel Xeon D-2123IT
Clock frequency
2.20 GHz
Max. turbo clock rate
3 GHz
Number of processor cores
4 -Core

Network connections

Network connections
RJ45 (3x)

Wireless transmission

Connectivity
Ethernet, LAN, RJ45, USB

Additional connections

USB ports
USB-A
Exact USB ports
USB-A 3.2 Gen 1 (2x)

Mains supply properties

Power consumption
500.87 W
Number of fans
3x
Fan diameter
60 mm
Redundant power supply unit
Yes

Origin

Country of origin
Taiwan

Voluntary climate contribution

CO₂ emissions
15.31 kg
Climate contribution
CHF 0.37

Scope of delivery

Scope of delivery
AC, Lan (RJ-45)

Product dimensions

Length
63.06 cm
Width
48.31 cm
Height
13.20 cm
Weight
25.83 kg

30-day right of return
24 Months Warranty (Bring-in)
