Phoenix Contact PCB terminal block, 5.08mm pitch, 3 way

Number of contacts: 3
Pitch: 5.08 mm
Number of rows: 1
Mounting type: Through-hole mounting
Gender: Male
Connection type: Screw
Type: PCB terminal block
Rated current: 17.5 A
Housing orientation: Straight
Color: Green
Operating voltage: 400 V
Series: COMBICON MKDS
Material: Polyamide
Depth: 13.8 mm

Connection according to standard EN-VDE, V0 flammability class according to UL 94, DIN EN 60512-5-2:2003-01. Order number 804-4991 has the position number stamped on the housing, 883-2921 is internally bridged. The COMBICON MKDS PCB terminal blocks with a pitch of 5.08 mm are designed for through-hole mounting, feature screw connection terminals with contact springs, and a side locking mechanism. Features and benefits: Well-known connection principle allows for worldwide use, low temperature rise due to optimal contact force, enables connection of two conductors, integrated protective guide prevents incorrect insertion of the conductor under the clamping sleeve, side locking allows for the combination of different numbers of positions, RoHS compliant.
