Phoenix Contact GMVSTBW 2.5/ 7-ST-7.62

PCB connector, rated current: 12 A, rated voltage (III/2): 630 V, number of poles: 7, pitch: 7.62 mm, connection type: screw connection with tension sleeve, color: green, contact surface: Tin Well-known connection principle allows worldwide use Low heating due to highest contact force Allows connection of two conductors Integrated steel over-spring for additional safety in case of temperature and power fluctuations Key features Technical details Number of poles 7 Product color Green Certification EN-VDE, CSA, REACH, RoHS Current consumption 12 A Coating Connection terminals Tin Cable section (AWG) 24 - 12 Input connector capacity 2.5 mm² Connector gender Male Weight & Dimensions Width 51.3 mm Depth 12.5 mm Height 26 mm Energy Rated voltage 630 V.
