Phoenix Contact GMVSTBW 2.5/ 5-ST-7.62

The GMVSTBW 2.5/5-ST-7.62 is a high-quality printed circuit board connector designed for a variety of applications in electrical engineering. With a rated current of 12 A and a rated voltage of 630 V, this connector provides a reliable connection for electrical systems. The five poles and a pitch of 7.62 mm allow for flexible integration into different circuits. The screw connection with a strain relief ensures a secure and stable connection, while the tin coating on the contact surface guarantees optimal conductivity. The connector is designed for the connection of two conductors and features an integrated steel spring for added safety during temperature and performance fluctuations. With an operating temperature range of -40 °C to 100 °C, this connector is suitable for demanding environments and meets the certifications EN-VDE, CSA, REACH, and RoHS.

• Allows the connection of two conductors for flexible applications
• Integrated steel spring for increased safety during temperature fluctuations
• High contact force minimizes heating during operation
• Tin coating on the contact surface for optimal conductivity
• Certified according to EN-VDE, CSA, REACH, and RoHS for international use.
