Phoenix Contact FMC 1,5/3-STF-3,5 Plug 3way 3.5mm

Ratings
BrandMore from Phoenix Contact
Delivered Mon, 31.8.
More than 10 pieces in stock at third-party supplier
Supplied by
Conrad CH
free shipping

Show all

Product details

Number of contacts: 3
Type: Connector
Series: MINI COMBICON FMC

Plug-in terminal block connectors MINI COMBICON FMC and FMCD from Phoenix Contact. Plug-in terminal block connectors of the MINI COMBICON FMC 1.5 and FMCD 1.5 series with a 3.5 mm pitch for cable mounting, featuring a flat 7.8 mm design and tool-free push-in spring connection terminals. The free-hanging connectors of the MINI COMBICON FMC 1.5 and FMCD 1.5 series with a 3.5 mm pitch have sockets, a connection for voltage testing, and a test probe with a diameter of 1 mm. They can be used with the PCB terminal block pin headers of the MINI COMBICON MC 1.5 series with a 3.5 mm pitch. Part numbers prefixed with 19520 and 19521 have a self-locking flange (FMC 1.5 - ST - RF). Part numbers prefixed with 1966 have a screw connection flange (FMC 1.5 - STF). Part numbers prefixed with 1738 have 2 rows (FMCD 1.5 - ST). Suitable crimping tool for ferrules. 3.5 mm pitch wire size range 24-16 AWG spring cage cable-to-board.

Key specifications

Cable + connector type
Plug connectors

General information

Item number
10097389
Manufacturer
Phoenix Contact
Category
Cables + Plugs
Manufacturer No.
1966101
Release date
12.11.2018

Colour

Colour
Green

Material

Material group
Metal, Plastic
Material
Copper, Pewter, Thermoplastic resin

Cable + Connector Features

Cable + connector type
Plug connectors
Temperature
-40 - 100 °C
Max. temperature
100 °C
Min. temperature
-40 °C
mounting type
Cable installation
Connectors Design
Socket, straight
Number of cores
3x

Voluntary climate contribution

CO₂ emissions
0.25 kg
Climate contribution
CHF 0.11

Scope of delivery

Items per sales unit
50 pcs.
Scope of delivery
50 pc(s)

Product dimensions

Length
2.29 cm
Width
2.08 cm
Height
0.78 cm
Weight
136 g
