Product details
Number of levels: Single
Wire size: 26 → 10 AWG
Connector count: 2
Color: Black
Grid: 6.2mm
Fuse size: 5 x 20mm
Rated current: 6.3A
Operating voltage: 500V
Connection type: Screws
Profile rail compatibility: NS35
Series: UT
Operating temperature max.: +110°C
Operating temperature min.: -50°C
Approval for hazardous areas: ATEX II 2 G D EX e II. KEMA 04ATEX2048 U. The listed cable cross-section refers to solid conductors. UT terminals. All metal parts are made of high-strength copper alloy. Simple multi-pole connection. Maintenance-free "Reakdyn principle." All accessories are compatible with the CLIPLINE series.
Item number | 10407066 |
Manufacturer | Phoenix Contact |
Category | Electronics supplies + Casing |
Manufacturer no. | 3046032 |
Release date | 5.2.2019 |
External links | |
Minimum order | 4 |
Minimum order | 4 |
Colour | Black |
Compatible hardware | Various |
Manufacturer Type | Ut 4-hesi (5x20) |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 50 x |
Scope of delivery | Fuse terminal 500V 6.3A 0.14-6qmm |
Length | 73 mm |
Width | 6.20 mm |
Height | 57.80 mm |
Specifications may include unverified machine translations.
