Product details
Peiyinga amplifiers are perfectly combinable in design and technology with Peiyinga radios and subwoofers. They are protected against overload and heat, feature strong terminal connections, high output power, and extensive bass control. Some amplifier models include a linear output and bass and treble correction functions. Despite their relatively small dimensions, they achieve high performance. The casing, made from a special aluminum alloy, effectively dissipates the heat generated by the device. With a wide selection of amplifiers, you can tailor the sound to the acoustics of any vehicle's interior.
Specification:
Model: PY-B4C110R
Power at 4 Ohms: 4 x 75 W
Power at 2 Ohms: 4 x 110 W
Bridged power at 4 Ohms: 2 x 185 W
Minimum speaker impedance: 2 Ohms
Total harmonic distortion: 0.08%
Sensitivity: 0.2 V ~ 6 V
Input impedance: 10,000 Ohms
S/N ratio: 90 dB
Channel separation: 50 dB
Bass remote control: 0.2 V ~ +6 V
Low band filter: 50 Hz ~ 500 Hz
Bass boost: 0 dB ~ +12 dB
Shielding: 2x 25
Power supply: 11-14.5 V DC
Dimensions: 414 x 200 x 49 mm.
