MSI PRO B860-P

LGA 1851, Intel B860, ATX
1Ratings
BrandMore from MSI
Delivered tomorrow
Only 1 piece in stock
free shipping

Product details

The Pro B860-P offers a simple design with a harmonious silver colour scheme that perfectly matches white and black PC builds. It is equipped with many MSI exclusive functions, including 5G LAN, Thunderbolt 4, PCIe 5.0 M.2 and additional PCIe power supply, ready for Intel Core Ultra processors.

Key specifications

Processor family
Core Ultra 5 2nd Gen, Core Ultra 7 2nd Gen, Core Ultra 9 2nd Gen
Memory type
DDR5 RAM
Mainboard features
Serial header, Trusted Platform Module
Internal connection options
M.2 (3x), S-ATA III (4x)
Number of memory modules (RAM)
4x
Item number
53472968

General information

Manufacturer
MSI
Category
Motherboards
Manufacturer no.
7E41-002R
Release date
3.12.2024
External links
Manufacturer's site (de)

Motherboard properties

Form factor
ATX
Socket
LGA 1851
Chipset
Intel B860
Mainboard features
Serial header, Trusted Platform Module
Operating system compatibility
Windows
BIOS type
UEFI AMI

Processor

Processor family
Core Ultra 5 2nd Gen, Core Ultra 7 2nd Gen, Core Ultra 9 2nd Gen

Memory

Memory form factor
DIMM
Number of memory modules (RAM)
4x
Max. memory (RAM)
256 GB
Memory chip
DDR5 SDRAM
Max. RAM OC
8800 MHz
Supported memory speed
4800 MHz, 6400 MHz
Memory type
DDR5 RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
HDMI (1x)
Video connection version
HDMI 2.1

Network

Network connections
RJ45 (1x)
Ethernet controller brand
Realtek
Ethernet controller
Gigabit Ethernet
Max. port speed
5 Gbit/s

Audio

Chip
Realtek ALC897
Audio channel
7.1 Channel

Data storage

RAID configuration
0, 1, 10, 5

Internal interfaces

Internal connection options
M.2 (3x), S-ATA III (4x)
Expansion slot
PCI Express x1 (2x), PCI Express x16 (1x), PCI Express x16 (3x)
PCI express version (max.)
5
Number of fan connector
1

Further connections

USB ports
USB-A, USB-C
Exact USB ports
USB-A 2.0 (4x), USB-A 3.2 Gen 1 (2x), USB-C 3.2 Gen 2 (1x)

Power supply

Power connectors
24-pin ATX, 8-pin ATX 12V

Origin

Country of origin
China

Sustainability

Manufacturer commitment
SBTi

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Cable ties, Cover for housing

Product dimensions

Length
304.80 mm
Width
243.80 mm
Height
304.80 mm
Weight
1420 g

Package dimensions

Length
35.20 cm
Width
27.30 cm
Height
7.50 cm
Weight
1.40 kg
