The MAG series accompanies you on the path to victory. The military-inspired elements in this series serve as a symbol of robustness and durability.
Processor family | AMD 7000 Series |
Memory type | DDR5 RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | M.2 (1x), S-ATA III (1x) |
Wireless transmission | Bluetooth, Wi-Fi |
Mainboard features | Front panel audio connector, RGB header |
Item number | 24918617 |
Manufacturer | MSI |
Category | Motherboards |
Manufacturer no. | 7E12-001R |
Release date | 9.5.2023 |
Sales rank in Category Motherboards | 51 of 1038 |
Form factor | ATX |
Socket | AM5 |
Chipset | AMD X670E |
Mainboard features | Front panel audio connector, RGB header |
Operating system compatibility | Windows 10, Windows 11 Home, Windows 11 Pro |
BIOS type | UEFI |
Wireless transmission | Bluetooth, Wi-Fi |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Processor family | AMD 7000 Series |
Memory form factor | DIMM |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 256 GB |
Memory chip | DDR5 SDRAM |
Max. RAM OC | 6600 MHz |
Supported memory speed | 4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz, 6000 MHz, 6200 MHz, 6400 MHz, 6600 MHz |
Memory type | DDR5 RAM |
RAM buffer | Unbuffered |
Video connections | DisplayPort, HDMI Type A |
Video connection version | Display port 1.4, HDMI 2.1 |
Network connections | RJ45 2.5 Gigabit Ethernet (1x) |
Ethernet controller brand | Realtek |
Ethernet controller | Realtek RTL8125-BG |
Max. port speed | 2.50 Gbit/s |
Chip | Realtek ALC1200 |
Audio channel | 7.1 Channel |
Audio Connections | HDMI (1x), Microphone |
RAID configuration | 0, 1, 10 |
Internal connection options | M.2 (1x), S-ATA III (1x) |
Expansion slot | PCI Express x1 (Gen 3) (1x), PCI Express x16 (4x), PCI Express x16 (5x) |
PCI express version (max.) | 5 |
Number of fan connector | 1 |
USB ports | USB-A |
Exact USB ports | USB-A 2.0 (4x), USB-A 3.2 Gen 1 (4x), USB-A 3.2 Gen 2 (2x) |
Power connectors | 20+4-pin ATX |
Country of origin | China |
Manufacturer commitment | SBTi |
CO₂-Emission | |
Climate contribution |
Scope of delivery | HD Audio (8-channel) |
Length | 304.80 mm |
Width | 243.84 mm |
Height | 270 mm |
Weight | 1500 g |
Length | 35.60 cm |
Width | 27.90 cm |
Height | 7.40 cm |
Weight | 2 kg |
