Product details

The Monitor S 80 ATM is one of the technological highlights of the series. This is due to the Dolby Atmos module integrated into the top. This coaxial speaker, specially developed according to Dolby's guidelines, consists of a 100 mm mid-bass driver and a 20 mm tweeter.

Key specifications

Speaker type
Dolby Atmos speaker
Loudspeaker construction
Passive speakers
Application range
Hi-fi, Home cinema
Nominal power
160 W

General information

Item number
23101293
Manufacturer
Magnat
Category
Hi-fi + Home cinema speakers
Manufacturer No.
D144806
Release date
15.11.2022

Application range

Sales unit
1 pcs.
Speaker type
Dolby Atmos speaker
Loudspeaker construction
Passive speakers
Application range
Hi-fi, Home cinema
Speaker design
Floorstanding speaker
Bass reflex port
Front port

Colour

Colour
Black
Exact colour description
Black
Gloss level
Silk gloss

Material

Material group
Wood
Material
MDF

Passive speaker properties

Speaker principle
2.5-way
Recommended amplifier power
30 - 300 Watt (W)
Nominal power
160 W
Power handling capacity (max.)
300 W
Impedance
4 Ohm
Efficiency
90 dB

Playback frequency properties

Transmission range
26 - 38000 Hz
Crossover frequency
7000 Hz

Connection to main device

Audio Connections
Screw terminals

Woofer

Diameter
165.10 mm

Woover / Midrange loudspeaker

Number
2x
Diameter
165.10 mm

Midrange loudspeaker

Number
2x
Diameter
165.10 mm

Mid-range speaker / Tweeter

Number
1x
Diameter
114.30 mm

Tweeter

Tweeter type
Dome tweeter
Material
Dome tweeter
Number
1x
Diameter
27.94 mm

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂ emissions
99.72 kg
Climate contribution
CHF 2.37

Scope of delivery

Scope of delivery
Manual

Product dimensions

Width
215 mm
Height
860 mm
Depth
270 mm
Weight
13.40 kg

Package dimensions

Length
32.50 cm
Width
27 cm
Height
93 cm
Weight
15 kg
