Lenovo ThinkPad E560
15.60", Intel Core i7-6500U, 16 GB, 192 GB, CHProduct details
The ThinkPad E560 is ideally suited for individuals who frequently switch between office and fieldwork. With its sixth-generation i7 processor, 16 GB of RAM, and dedicated AMD graphics card, it delivers performance that can rival desktop PCs. A fingerprint scanner protects it from unauthorized access. Thanks to the extra-large touchpad with gesture control, a separate numeric keypad, and a TrackPoint, you can operate the E560 quickly and precisely from anywhere – and it lasts up to 9 hours on battery power.
Whether in the office or on the go, a generous selection of ports keeps you connected at all times. With 1000 Mbps LAN and 802.11ac Wi-Fi, you can navigate any network quickly. Present your work with a projector or connect a second screen – both are easy with an HDMI and a VGA port. Three USB 3.0 ports and a OneLink port are available for your peripherals and docking station. You won't have to miss out on a card reader either.
For mass storage, a 192 GB Solid-State Drive (SSD) provides the necessary space. The main advantage of SSDs is their fast access times and high read and write speeds, which overshadow traditional hard drives – the difference is noticeable right from the moment you boot up the computer. Another benefit is that SSDs contain no moving parts, leading to increased durability since no components wear out mechanically. Additionally, SSDs operate completely silently.
Processor family | Core i7 6th Gen |
Memory | 16 GB |
SSD capacity | 192 GB |
Operating System Version | Windows 7 Pro / Windows 10 ready |
Image resolution | 1920 x 1080 pixels |
Keyboard layout | Swiss |
Graphics card model | Radeon R7 M370 |
Item number | 5659400 |
Manufacturer | Lenovo |
Category | Notebooks |
Manufacturer no. | 20EV000XMZ |
Release date | 10.12.2015 |
Colour | Black |
Exact colour description | Black |
Notebook type | Business laptop |
Processor family | Core i7 6th Gen |
Processor type | Intel Core i7-6500U |
Clock frequency | 2.50 GHz |
Max. turbo clock rate | 3.10 GHz |
Max. TDP | 25 W |
Number of processor cores | 2 -Core |
Number of threads | 4 |
Cache | 4 MB |
Chipset | Intel SoC |
Memory | 16 GB |
Memory configuration | 2 x 8GB |
Max. supported memory | 16 GB |
Memory type | DDR3L-RAM |
Memory form factor | SO-DIMM |
Storage clock frequency | 1600 MHz |
Material group | Plastic |
Material | ABS, Acrylonitrile Butadiene Styrene (ABS) |
Graphics chip (GPU) | Intel HD Graphics |
Graphics card model | Radeon R7 M370 |
Graphics card model | Radeon R7 M370 |
Dedicated graphics memory | 2 GB |
Video memory type | GDDR5 |
Display resolution | Full HD |
Image resolution | 1920 x 1080 pixels |
Aspect ratio | 16:9 |
Display functions | Integrated microphone |
Display size (inches) | 15.60" |
Screen surface | Anti-glare |
Brightness | 250 cd/m² |
Disk type | SSD |
Total capacity | 192 GB |
SSD capacity | 192 GB |
Optical drive type | DVD writer |
Memory card type | MMC, SD, SDHC, SDXC |
Video connections | HDMI (1x) |
Audio Connections | HDMI (1x) |
Network connections | RJ45 (1x) |
Operating system | Windows |
Operating System Version | Windows 7 Pro / Windows 10 ready |
Language | English, French, German, Italian |
Operating system architecture | 64-bit |
Notebook speaker type | JBL stereo speakers, Stereo speakers |
Number of speakers | 2 x |
Audio channel | Stereo |
Max. Video resolution front camera | 1280 x 720 pixels |
Safety | Fingerprint scanner |
Password protection Type | Hard disk, Supervisor, Switch on |
Max. port speed | 1 Gbit/s |
Wireless transmission | Bluetooth, Wi-Fi |
Wi-Fi controller | Intel Wireless-AC 3165 |
Wi-Fi standard | Wi-Fi 1 / 802.11b, Wi-Fi 2 / 802.11a, Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n, Wi-Fi 5 / 802.11ac |
Battery type | Li-ion |
Number of cells | 6 Cells |
Max. battery life | 9 h |
Power supply unit strength | 65 W |
Keyboard layout | Swiss |
Input device | Numeric keypad, Touchpad, TrackPoint |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Instruction manual |
Height | 2.71 cm |
Depth | 25.50 cm |
Width | 37.70 cm |
Weight | 2.45 kg |
Length | 49 cm |
Width | 33.20 cm |
Height | 9 cm |
Weight | 7.11 kg |
