JUNG Push-button module 24 V AC/DC A5248TSM

Jung Touch Sensor Module 4-fold A 5248 TSM

Manufacturer: Jung
Designation: Touch Sensor Module 4-fold AC/DC 24V 4-channel 8-position
Type: A 5248 TSM
Composition: Base element
Design: Other
Operating method: Rocker
Number of operating rockers: 4
Number of modules (in modular design): 1
Nominal voltage: 0 V
Rated current: 0.02 A
With lighting: No
With signal lamp: No
Mounting type: Flush-mounted
Mounting method: Screw fastening
Material: Other
Material quality: Other
Halogen-free: Yes
Antibacterial treatment: No
Text field/Labeling area: No

The Jung Touch Sensor Module 4-fold A 5248 TSM offers additional details including a transparent cover. It is a multi-wire system for connection to the relay station or dimming station as well as other control systems with a control voltage of up to 24 V AC/DC (SELV), 20 mA. The connection is made via a terminal block on the back. A completion with a touch set is planned, with one red status LED per button.
EAN: 4011377118119.
