JUNG KNX Smart Panel 8 SP0081U

Intended Use: Visualizing and operating system statuses in building automation. Horizontal installation is recommended, but vertical installation is also possible. Installation in flush-mounted housing Art. No. EBG 24 or on a device box with dimensions according to DIN 49073, recommendation: approximately 60 mm deep.

Product Features:

• High-resolution HD display
• Proximity sensor
• Capacitive touchscreen
• Cleaning mode with touchscreen lock
• Fanless, without mechanically moving parts
• Integrated bus coupler
• Graphical user interface for visualizing and operating KNX devices
• Project planning with Windows software "KNX Smart Panel Designer," minimum requirements: Windows 10, 64-bit, 120 MB free storage space
• Commissioning with ETS from version 5.7.4 and DCA
• KNX special functions, e.g., scenes, sequences, central function, presence simulation
• Rooms or elements: max. 300
• Structuring by multiple rooms or as single rooms
• Scheduling: max. 125 with 10 commands each
• Logical links: max. 55
• Astronomical clock
• Visualization of indoor and outdoor temperature
• Automatic temperature averaging per room
• Notifications: Alarm, Warning, Information
• Email notification
• Push notification
• Favorites page
• Color scheme: light/dark
• Two-level configuration access: Admin, User
• User management
• User PIN codes: max. 10
• PIN protection for rooms and elements
• Backup and restore
• Mobile app
• Secured remote access via a myJUNG account SP-REMOTE-L required
• App users per installation: max. 10
• Door intercom function only in conjunction with the Smart Gateway SG 650-.. or SG 150-.. from Siedle SP 0081 U.
