Intel NUC NUC8i7BEH2 - Bean Canyon
Intel Core i7-8559UFree shipping starting at 50.–
The built-in Intel Core processor of the eighth generation is based, like its predecessor, on the energy-efficient 14nm architecture, which does not overheat even under full load, but delivers more performance while maintaining the same power consumption. The main innovations include various performance optimizations and an increased number of physical and virtual cores, which provide a significant boost in performance and smooth multitasking. The graphics solution allows for many features that were previously reserved for dedicated graphics cards – from video editing to gaming and 4K video playback. Thanks to Turbo Boost 2.0, it can dynamically adjust its clock speed to find the optimal balance between energy consumption and performance.
Number of processor cores | 4 -Core |
Graphics card model | Iris Plus Graphics 655 |
Internal connection options | M.2 (1x), S-ATA III (1x) |
Network connections | RJ45 (1x) |
Video connections | HDMI (1x) |
Memory type | DDR4-RAM |
USB ports | Thunderbolt 3, USB-A |
Item number | 9877627 |
Manufacturer | Intel |
Category | Barebones |
Manufacturer no. | BOXNUC8I7BEH2 |
Release date | 9.10.2018 |
Design | Small Form |
Processor type | Intel Core i7-8559U |
Clock frequency | 2.70 GHz |
Number of processors | 1 x |
Number of processor cores | 4 -Core |
Number of threads | 8 |
Socket | BGA 1528 |
Max. turbo clock rate | 4.50 GHz |
Max. TDP | 28 W |
Processor properties | Intel Virtualisation Technology (VT-x) |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Number of pins | 260 x |
Memory chip compatibility | DDR4-2400 |
Memory Slots available | 2 |
Max. memory slots | 2 |
Max. RAM | 32 GB |
Memory voltage | 1.20 V |
Graphics card model | Iris Plus Graphics 655 |
Max. connected monitors | 3 x |
Internal connection options | M.2 (1x), S-ATA III (1x) |
RAID configuration | 0, 1 |
"Number of 2.5"" drive slots" | 1 x |
USB ports | Thunderbolt 3, USB-A |
Exact USB ports | Thunderbolt 3 (1x), USB-A 3.1 Gen 1 (4x) |
Network connections | RJ45 (1x) |
Max. port speed | 1000 Mbit/s |
Connectivity | Bluetooth, WLAN |
Wi-Fi standard | Wi-Fi 1 / 802.11b, Wi-Fi 2 / 802.11a, Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n, Wi-Fi 5 / 802.11ac |
Bluetooth version | 5.0 |
Video connections | HDMI (1x) |
Audio outputs | 3.5mm jack (1x) |
Memory card type | microSDXC |
Power | 65 W |
CO₂-Emission | |
Climate contribution |
Scope of delivery | PC Barebone |
Width | 117 mm |
Length | 112 mm |
Height | 51 mm |
Length | 15.50 cm |
Width | 12 cm |
Height | 13 cm |
Weight | 1.29 kg |
