This barebone is equipped with an Intel 8th Gen Mobile Core processor, which is combined with an AMD Radeon RX Vega graphics unit in the same package. This exceptional combination eliminates the weaknesses of Intel's own HD graphics unit, allowing the NUC8i7HVK to provide a smoother gaming experience. The graphics performance is expected to be similar to that of an Nvidia GeForce GTX 1060.
Number of processor cores | 4 -Core |
Graphics card model | Radeon RX Vega M GH |
Internal connection options | M.2 (2x) |
Network connections | RJ45 (2x) |
Video connections | HDMI (2x), Mini DisplayPort (2x) |
Memory type | DDR4-RAM |
USB ports | Thunderbolt 3, USB-A |
Item number | 8359828 |
Manufacturer | Intel |
Category | Barebones |
Manufacturer no. | BOXNUC8I7HVK2 |
Release date | 16.4.2018 |
Design | Ultra Slim |
Processor type | Intel Core i7-8809G |
Clock frequency | 3.10 GHz |
Number of processors | 1 x |
Number of processor cores | 4 -Core |
Number of threads | 8 |
Socket | BGA 2270 |
Max. turbo clock rate | 4.20 GHz |
Max. TDP | 100 W |
Processor properties | 64-bit architecture, Direct I/O Virtualization Technology (VT-d) |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Number of pins | 260 x |
Memory chip compatibility | DDR4-2400 |
Memory Slots available | 2 |
Max. memory slots | 2 |
Max. RAM | 32 GB |
Memory voltage | 1.20 V |
Graphics card model | Radeon RX Vega M GH |
Hardware application range | Beginner, Gaming |
Max. connected monitors | 6 x |
Internal connection options | M.2 (2x) |
RAID configuration | 0, 1 |
USB ports | Thunderbolt 3, USB-A |
Exact USB ports | Thunderbolt 3 (2x), USB-A 3.0 (6x), USB-A 3.1 Gen 1 (1x) |
Network connections | RJ45 (2x) |
Max. port speed | 1000 Mbit/s |
Connectivity | Bluetooth, WLAN |
Wi-Fi standard | Wi-Fi 5 / 802.11ac |
Bluetooth version | 4.2 |
Video connections | HDMI (2x), Mini DisplayPort (2x) |
Audio outputs | 3.5mm jack (1x) |
Memory card type | SDXC |
Power | 230 W |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1 x power supply |
Width | 221 mm |
Length | 142 mm |
Height | 39 mm |
Length | 27.50 cm |
Width | 19.70 cm |
Height | 12.30 cm |
Weight | 2.96 kg |
How often does a product of this brand in the «Barebones» category have a defect within the first 24 months?
Source: Digitec GalaxusHow many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?
Source: Digitec GalaxusHow often is a product of this brand in the «Barebones» category returned?
Source: Digitec Galaxus
Der Mini-PC NUC8I7HVK taugt fürs Full-HD-Gaming sowie für VR-Anwendungen und belegt kaum Platz auf dem Tisch. Der Kombiprozessor mit Vega-GPU liefert eine 3D-Performance auf dem Niveau von Desktop-PC-Grafikkarten, die 200 Euro kosten. Zudem hat Intel dem NUC ein umfangreiches Schnittstellenangebot mit sechs Display-Anschlüssen, Thunderbolt 3 und zwei Ethernet-Buchsen spendiert...
Mit dem NUC 8i7HVK ist Intel ein richtig guter Mini-PC gelungen. Im Test bietet der Rechner mit dem knallharten Spitznamen "Hades Canyon" hohe CPU- und gute Gaming-Leistung zum fairen Preis. Auch eine tolle Anschluss-Vielfalt ist gegeben. Da es sich um ein Barebone handelt, müssen Sie SSD und Arbeitsspeicher aber selbst kaufen und einbauen...
