Inactive Status
Idle states (C-states) are used to save energy when the processor is idle. C0 is the active state, meaning the CPU is performing useful tasks. C1 is the first idle state, C2 is the second, and so on, with higher C-state numbers implementing more energy-saving measures.
Enhanced Intel SpeedStep® Technology
The enhanced Intel SpeedStep® technology is an advanced feature designed for mobile devices that require a combination of high performance with minimal energy consumption. The traditional Intel SpeedStep® technology adjusts voltage and frequency simultaneously between high and low values based on processor load. The enhanced Intel SpeedStep® technology builds on this architecture and employs design strategies such as separating voltage and frequency changes as well as clock partitioning and recovery.
Thermal Monitoring Technology
Thermal monitoring technology protects the processor package and the system from temperature-related failures through temperature management functions. A digital on-die temperature sensor detects the core temperature, and the temperature management functions reduce the package's energy consumption and thus the temperature as needed to maintain the limits for normal operation.
Processor family | Core i5 5th Gen |
Number of processor cores | 4 -Core |
Max. TDP | 65 W |
Number of threads | 4 |
PCI express version (max.) | 3 |
Item number | 5297176 |
Manufacturer | Intel |
Category | Processors |
Manufacturer no. | BX80658I55675C |
Release date | 23.6.2015 |
Processor family | Core i5 5th Gen |
Socket | LGA 1150 |
Intel Core | Broadwell-K |
Clock frequency | 3.20 GHz |
Max. turbo clock rate | 3.60 GHz |
Number of processor cores | 4 -Core |
Number of threads | 4 |
Lithography | 14 nm |
Max. TDP | 65 W |
L1 Cache | 64 kB |
L2 Cache | 256 kB |
L3 Cache | 4 MB |
Multiplier unlocked | Yes |
PCI express version (max.) | 3 |
Processor design | 64-bit |
Front side bus frequency | 5000 MHz |
Transfer rate | 5 GT/s |
Intel technologies | AES-NI, AVX, Direct I/O Virtualization Technology (VT-d), Execute-disable bit, MMX, SSE, SSE2, SSE3, SSE4, Turbo Boost Technology, Virtualization technology (VT-x) |
Onboard graphics | Yes |
Graphics card model | Intel Iris Pro Graphics, Iris Pro Graphics 6200 |
DirectX version | 11.20 |
Max. connected monitors | 3 x |
Clock frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1100 MHz |
Memory channels | Dual-Channel |
Memory type | DDR3L-RAM |
Max. memory (RAM) | 32 GB |
CO₂-Emission | |
Climate contribution |
Length | 11.40 cm |
Width | 10.50 cm |
Height | 8.10 cm |
Weight | 330 g |
