IFM IM5037

Ifm Electronic Sensor,ind.,40x40,Clamp. IM5037 Manufacturer :Ifm Electronic Designation :Sensor,ind.,40x40,Clamp. DC,prg.,sn=15mm,b Type :IM5037 Width of the sensor :40 mm Height of the sensor :121 mm Length of the sensor :40 mm Switching distance :15 mm Housing :Cuboid Max. Output current at safe output :400 mA Supply voltage :10..55 V Rated control supply voltage Us at DC :10..55 V Voltage type :DC Material of housing :Plastic Ifm Electronic Sensor,ind.,40x40,Clamp. IM5037: more details Inductive sensors, Inductive sensor, Block-shaped plastic, Switching distance: 15 mm, Flush mountable, 2-wire, DC PNP/NPN, Operating voltage: 10...55 V DC, Normally open / Normally closed contact programmable, n.o. / n.c. progr., terminals, terminals up to 2.5 mm², material housing: PPE , EAN: 4021179130493.
