ifm Electronic IFM magnetic sensor

Ifm Electronic Magnetic sensor MS5011 Manufacturer :Ifm Electronic Designation :Magnetic sensor 10-30VDC,10mA Type :MS5011 Number of semiconductor outputs with signalling function :1 Type of actuation :metallic target Type of electrical connection :cable Type of switching output :PNP Sensor width :10.2 mm Sensor height :36.8 mm Sensor length :16 mm Explosion protection category for gas :none Explosion protection category for dust :none Housing design :cuboid Housing material :plastic Coating housing :uncoated Ambient temperature :-25..75 °C Rated supply voltage for DC :10...30 V Voltage type :DC Cross/short-circuit detection possible :no Switching distance :60 mm With monitoring function of downstream devices :no Suitable for safety functions :no Protection class (IP) :IP67 Ifm Electronic MS5011 magnetic sensor: more details Magnetic sensors, cylinder sensors, magnetic sensor, plastic housing, switching distance: 60 mm, 3-wire, DC PNP, operating voltage: 10...30 V DC, current consumption: 10 mA, NO contact, n.o., Connection cable, 2 m, PUR / PVC cable, 3 x 0.14 mm², Housing material: Housing: PBT orange , EAN: 4021179151917.
