ifm Electronic Cylinder sensor

Ifm Electronic Cylinder sensor AMR cell MK5140 Manufacturer :Ifm Electronic Designation :Cylinder sensor AMR cell DC PNP S Type :MK5140 Number of semiconductor outputs with signalling function :1 Type of actuation :Solenoid Type of electrical connection :Cable Type of switching output :PNP Sensor width :5 mm Sensor height :6.5 mm Sensor length :25.3 mm Explosion protection category for gas :None Explosion protection category for dust :None Housing design :Profile Housing material :Plastic Coating housing :Uncoated Max. Max. output current at safe output :100 mA Ambient temperature :-25..85 °C Mechanical installation condition for sensor :flush Rated supply voltage at DC :10...30 V Voltage type :DC Cross/short-circuit detection possible :no With monitoring function of downstream devices :no Suitable for safety functions :no Protection class (IP) :IP65 Ifm Electronic cylinder sensor AMR cell MK5140: more details Magnetic sensors, cylinder sensors, cylinder sensor with AMR cell, plastic housing for T-slot cylinders, flush-mountable, 3-wire, DC PNP, operating voltage: 10...30 V DC, current consumption: 10 mA, NO contact, n.o., Connection cable, 2 m, PUR cable, 3 x 0.14 mm², Housing material: Housing: PA (polyamide) Mounting eccentric stainless steel , EAN: 4021179151665.
