Hager TYMS620D

Switching Shutter Actuator 2010 KNX Secure, 16A, C-Load. The REG KNX Secure switching shutter actuator is designed for switching independent loads or controlling drives with potential-free contacts and can be connected in multiple phases. It is a DIN rail-mounted device with an integrated bus coupler. The bus connection is made via a KNX terminal block, and there is a toggle switch for auto/manual as well as manual buttons. The actuator channel features a status LED for default, short circuit, overload, a programming button with integrated LED, a labeling field, and screw terminals for input and output voltages. No external power supply is required.

Switching functions: On/Off, time control, safety off, forced control, switching function for time or duration, operating hour counter, device diagnosis, lock logic, preset, delay or scene functions (64 scenes).

Functions for roller shutter drive: Up/Down, Stop, slat position stop, percentage control to drive to a predefined position, sun protection function, e.g., via an external sensor, alarm function for a defined position, safety lock, device diagnosis, lock logic, preset or scene functions (64 scenes).

Note: The device can be programmed with ETS version 5 and the Hager Easytool. The range of functions depends on the commissioning. Please observe the installation instructions for actuators from the manufacturer. TYMS620D.
