Hager Ground fault circuit interrupter

2Ratings
BrandMore from Hager
Delivered between Wed, 15.4. and Fri, 17.4.
More than 10 pieces in stock at third-party supplier
Supplied by
JACOB DE
free shipping

Rated current2

Residual current (rated differential current)2

Product details

Hager RCD CFA463D

Manufacturer: Hager
Designation: RCD 4-pole 63A/300mA, 6kA
Type: CFA463D
Number of poles: 4
Rated voltage: 400 V
Rated current: 63 A
Rated residual current: 0.3 A
Rated insulation voltage Ui: 500 V
Rated impulse voltage withstand Uimp: 4 kV
Power loss: 19.7 W
Mounting type: DIN rail
Residual current type: A
Selective type: no
Time-delayed type: no
Short-circuit strength (Icw): 6 kA
Surge current strength: 0.25 kA
Voltage type: AC
With locking device: yes
Frequency: 50 Hz
Additional devices possible: yes
Protection class (IP): IP20
Width in module units: 4
Installation depth: 70 mm
Ambient temperature during operation: -25..40 °C
Degree of pollution: 2
Connectable conductor cross-section multi-stranded: 1..16 mm²
Connectable conductor cross-section single-stranded: 1..25 mm²
RAL number (similar): 7005
Explosion-proof: no

Hager RCD CFA463D: additional details
4-pole residual current circuit breaker 6kA 63A 300mA type A. Residual current protective device (RCD) according to DIN EN 61008-1 (VDE 0664-10), DIN EN 61008-2-1 (VDE 0664-11) with Bi-Connect terminals at the bottom, external blue test button, and residual current indicator. Suitable for retrofitting additional devices. Connection terminals with wire insertion protection, labeling option directly on the device.

Key specifications

Circuit breaker type
Fault current circuit breaker
Mounting type
Top-hat rail
number of poles
4
Length
70 mm

General information

Item number
21468566
Manufacturer
Hager
Category
Residual-current device
Manufacturer no.
CFA463D
Release date
13.7.2022
External links
Manufacturer's site (de)

Colour

Colour
Grey
Exact colour description
Grey, White

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
Mounting type
Top-hat rail
number of poles
4
Tripping characteristic
A
Rated current
63 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
500 V
Residual current (rated differential current)
0.30 A
Protection type (IP code)
IP20

Origin

Country of origin
China

Voluntary climate contribution

CO₂ emissions
16.77 kg
Climate contribution
CHF 0.40

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
70 mm
Weight
320 g
