Gigabyte Z370n-Wifi

LGA 1151, Intel Z370, Mini-ITX
5Ratings
BrandMore from Gigabyte
Currently out of stock
Free shipping starting at 50.–

Product details

The GIGABYTE Z370N WIFI is a powerful Mini-ITX motherboard designed for Intel's 8th generation processor family. It supports Intel® Core™ i3, i5, and i7 processors via the LGA 1151 socket. With a maximum RAM capacity of 32 GB and support for DDR4 SDRAM, this motherboard provides a solid foundation for high-performance computing applications. The integrated Wi-Fi functionality allows for wireless connectivity, while the Gigabit Ethernet interface ensures a fast and reliable network connection. The Z370N WIFI is ideal for compact builds that require both performance and connectivity.

  • Supports up to 32 GB of DDR4 RAM with speeds up to 4400 MHz (OC)
  • Integrated Wi-Fi with support for multiple standards, including Wi-Fi 5 (802.11ac)
  • Two RJ45 ports for Gigabit Ethernet connectivity
  • RAID support for various configurations (0, 1, 5, 10)
  • 5.1-channel audio output for an enhanced sound experience.

Key specifications

Mainboard features
Front panel audio connector
Wireless transmission
Wi-Fi
Processor family
Core i3 8th Gen, Core i5 8th Gen, Core i7 8th Gen
Number of memory modules (RAM)
2x
Memory type
DDR4-RAM
Internal connection options
S-ATA III (4x)

General information

Item number
6596314
Manufacturer
Gigabyte
Category
Motherboards
Manufacturer no.
Z370N-WIFI
Release date
5.10.2017

Motherboard properties

Form factor
Mini-ITX
Socket
LGA 1151
Chipset
Intel Z370
Mainboard features
Front panel audio connector
Operating system compatibility
Windows 10 Home, Windows 10 Pro
BIOS type
UEFI AMI
Wireless transmission
Wi-Fi
Wi-Fi standard
Wi-Fi 5 / 802.11ac

Processor

Processor family
Core i3 8th Gen, Core i5 8th Gen, Core i7 8th Gen

Memory

Memory form factor
DIMM
Number of pins
288x
Number of memory modules (RAM)
2x
Max. memory (RAM)
32 GB
Memory chip
DDR4-2133, DDR4-2400, DDR4-2666
Max. RAM OC
4400 MHz
Supported memory speed
2133 MHz, 2400 MHz, 2666 MHz, 3000 MHz, 3200 MHz, 4400 MHz
Memory type
DDR4-RAM
RAM buffer
Unbuffered

Network

Network connections
RJ45 (2x)
Ethernet controller brand
Intel
Ethernet controller
Intel Gbe LAN
Max. port speed
1 Gbit/s

Audio

Chip
ALC1220
Audio channel
5.1 channels
Audio Connections
Coaxial S/PDIF (1x)

Internal interfaces

Internal connection options
S-ATA III (4x)
Expansion slot
PCI Express x16 (1x)
Number of fan connector
3

Power supply

Power connectors
24-pin ATX, 8-pin ATX 12V

Scope of delivery

Scope of delivery
User manual

Product dimensions

Length
170 mm
Width
170 mm
Height
170 mm

Package dimensions

Length
22.50 cm
Width
19.50 cm
Height
8 cm
Weight
1 kg
