Gigabyte GB-BER3H-5300 (rev. 1.0)

AMD Ryzen 3 5300U
Ratings
Currently out of stock
Free shipping starting at 50.–

Product details

The GIGABYTE GB-BER3H-5300 is a compact mini-PC barebone designed for a variety of applications. Equipped with a powerful AMD Ryzen 3 5300U processor and supporting up to 64 GB of DDR4 RAM, this system provides a solid foundation for both office and multimedia applications. Its small and space-saving form factor makes it ideal for environments with limited space. The GB-BER3H-5300 supports both HDD and SSD storage drives via PCI Express and Serial ATA III, allowing for flexible storage options. With a variety of connectivity options, including HDMI, USB-C, and RJ45, this barebone PC is well-equipped to meet modern demands. The integrated AMD Radeon Graphics ensures an engaging visual experience, while support for Wi-Fi 6 and Bluetooth 5.2 provides a fast and reliable wireless connection.

  • Supports up to 64 GB of DDR4 RAM with 2 memory slots
  • Integrated AMD Radeon Graphics for enhanced graphics performance
  • Diverse connectivity options, including HDMI and USB-C
  • Compatible with HDD and SSD storage drives via PCIe and SATA III
  • Compact form factor for space-saving applications.

Key specifications

Number of processor cores
4 -Core
Graphics card model
AMD Radeon Graphics
Internal connection options
M.2 SATA (1x)
Network connections
RJ45 (1x)
Video connections
HDMI (2x)
Memory type
DDR4-RAM
USB ports
USB-A, USB-C
Item number
22681867

General information

Manufacturer
Gigabyte
Category
Barebones
Manufacturer no.
GB-BER3H-5300
Release date
18.7.2022

Barebone properties

Design
Small Form

Processor

Processor type
AMD Ryzen 3 5300U
Clock frequency
2.60 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Number of threads
8
Max. turbo clock rate
3.80 GHz
Max. TDP
15 W

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Memory Slots available
2
Max. memory slots
2
Max. RAM
64 GB

Graphics card properties

Graphics card model
AMD Radeon Graphics

Internal connections

Internal connection options
M.2 SATA (1x)
"Number of 2.5"" drive slots"
1 x

External connections

USB ports
USB-A, USB-C
Exact USB ports
USB-A 3.2 Gen 1 (2x), USB-A 3.2 Gen 2 (3x), USB-C 3.2 Gen 2 (1x)

Network

Network connections
RJ45 (1x)

Wireless transmission

Connectivity
WLAN
Wi-Fi standard
Wi-Fi 6 / 802.11ax
Bluetooth version
5.2

Video connections

Video connections
HDMI (2x)

Audio connections

Audio outputs
3.5mm headphones

Power supply properties

Power
135 W

Origin

Country of origin
Taiwan

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
VESA bracket

Product dimensions

Width
139.10 mm
Length
134.20 mm
Height
52 mm

Package dimensions

Length
30 cm
Width
19 cm
Height
9 cm
Weight
1.84 kg
