Gigabyte Brix s GB-BRR3H-4300 (rev. 1.0)
AMD Ryzen 3 4300UFree shipping starting at 50.–
The Gigabyte BRIX s GB-BRR3H-4300 is an ultra-compact barebone PC designed for users seeking a powerful and customizable solution. Equipped with an AMD Ryzen 3 4300U processor, this mini PC kit delivers solid performance for various applications, from office tasks to multimedia use. The BRIX s supports up to 64 GB of DDR4 RAM and allows for the installation of both HDD and SSD storage drives via M.2 and SATA interfaces. With a variety of connectivity options, including USB 3.2, HDMI, and Mini DisplayPort, this barebone PC is versatile and ideal for users who need a compact yet powerful computer. The integrated support for Wi-Fi 6 and Bluetooth 5.2 ensures fast and reliable network connections, while the VESA wall mount adapter allows for flexible placement.
Number of processor cores | 4 -Core |
Graphics card model | AMD Radeon Graphics |
Internal connection options | M.2 (1x), S-ATA (1x) |
Network connections | RJ45 (1x) |
Video connections | HDMI (1x), Mini DisplayPort (1x) |
Memory type | DDR4-RAM |
USB ports | USB-A |
Documents | |
Item number | 15655855 |
Manufacturer | Gigabyte |
Category | Barebones |
Manufacturer no. | GB-BRR3H-4300 |
Release date | 14.4.2021 |
Design | Small Form |
Processor type | AMD Ryzen 3 4300U |
Clock frequency | 2.70 GHz |
Number of processors | 1 x |
Number of processor cores | 4 -Core |
Number of threads | 4 |
Socket | FP6 |
Max. turbo clock rate | 4.10 GHz |
Max. TDP | 15 W |
Processor properties | Onboard processor |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Number of pins | 260 x |
Memory chip compatibility | DDR4-3200 |
Max. memory slots | 2 |
Max. RAM | 64 GB |
Graphics card model | AMD Radeon Graphics |
Max. connected monitors | 4 x |
Internal connection options | M.2 (1x), S-ATA (1x) |
"Number of 2.5"" drive slots" | 1 x |
USB ports | USB-A |
Exact USB ports | USB-A 3.1 Gen 1 (5x) |
Network connections | RJ45 (1x) |
Max. port speed | 2500 Mbit/s |
Connectivity | Bluetooth |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Bluetooth version | 5.2 |
Video connections | HDMI (1x), Mini DisplayPort (1x) |
Audio outputs | 3.5mm jack (1x) |
Power | 90 W |
CO₂-Emission | |
Climate contribution |
Scope of delivery | VESA wall mounting adapter |
Weight | 1800000 g |
Width | 119.50 mm |
Length | 119.50 mm |
Height | 46.80 mm |
Length | 29 cm |
Width | 8 cm |
Height | 18 cm |
Weight | 1.60 kg |
