Gigabyte BRIX Pro GB-BXi7-4770R

Intel Core i7-4770R
2Ratings
Currently out of stock
Free shipping starting at 50.–

Product details

High-performance ultra-slim PC with i7-4770R processor. Fast, compact, and portable, this PC can be useful in a variety of applications. Additionally, it features Wi-Fi and can be mounted almost anywhere with its installation kit. Delivered without RAM and hard drive.

Key specifications

Number of processor cores
4 -Core
Graphics card model
Iris Pro Graphics 5200
Internal connection options
mSATA (1x), S-ATA III (1x)
Network connections
RJ45 (1x)
Video connections
HDMI (1x), Mini DisplayPort (1x)
Memory type
DDR3L-RAM
USB ports
USB-A
Documents
Manual.pdf
Item number
2459251

General information

Manufacturer
Gigabyte
Category
Barebones
Manufacturer no.
GB-BXi7-4770R
Release date
11.2.2014
External links
Specifications (en)

Barebone properties

Design
Ultra Slim

Processor

Processor type
Intel Core i7-4770R
Clock frequency
3.20 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Number of threads
8
Socket
FCBGA1364
Max. turbo clock rate
3.90 GHz
Max. TDP
65 W
Processor properties
64-bit architecture, Direct I/O Virtualization Technology (VT-d), Intel Virtualisation Technology (VT-x)

Memory

Memory type
DDR3L-RAM
Memory chip compatibility
DDR3L-1333 (PC3-10600), DDR3L-1600 (PC3-12800U)
Memory Slots available
2
Max. memory slots
2
Max. RAM
16 GB

Graphics card properties

Graphics card model
Iris Pro Graphics 5200

Internal connections

Internal connection options
mSATA (1x), S-ATA III (1x)

External connections

USB ports
USB-A
Exact USB ports
USB-A 3.0 (2x)

Network

Network connections
RJ45 (1x)
Max. port speed
1000 Mbit/s

Wireless transmission

Connectivity
Bluetooth, WLAN
Wi-Fi standard
Wi-Fi 1 / 802.11b, Wi-Fi 2 / 802.11a, Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n, Wi-Fi 5 / 802.11ac

Video connections

Video connections
HDMI (1x), Mini DisplayPort (1x)

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Manual, Power cord, Power supply, VESA kit

Product dimensions

Width
111.40 mm
Length
114.40 mm
Height
62 mm
