Gewiss Ground fault circuit interrupter

2Ratings
BrandMore from Gewiss
Delivered between Tue, 24.2. and Thu, 26.2.
More than 10 pieces in stock at supplier
Free shipping starting at 50.–

number of poles2

Rated current2

Product details

Gewiss Residual Current Circuit Breaker GWD4032

Manufacturer: Gewiss
Designation: Residual Current Circuit Breaker 2-p, 40A, 30mA
Type: GWD4032
Number of Poles: 2
Rated Voltage: 230 V
Rated Current: 40 A
Rated Residual Current: 0.03 A
Rated Insulation Voltage Ui: 500 V
Rated Impulse Voltage Resistance Uimp: 4 kV
Power Loss: 7.8 W
Mounting Type: DIN Rail
Residual Current Type: A
Selective Type: No
Time Delay Type: No
Short-Circuit Strength (Icw): 10 kA
Surge Current Strength: 0.25 kA
Voltage Type: AC
With Locking Device: No
Frequency: 50/60 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Division Units: 2
Installation Depth: 72 mm
Ambient Temperature During Operation: -25..40 °C
Degree of Pollution: 2
Connectable Conductor Cross-Section Multi-Stranded: 35 mm²
Connectable Conductor Cross-Section Solid: 35 mm²
Explosion Protected: No

The residual current circuit breaker is a voltage-independent residual current device (RCCB) according to EN61008-1. It is suitable for retrofitting 2 additional devices and/or combinations with modules for automatic reset (Restart). The switch lever can be sealed in both the off and on positions and is lockable with a padlock using a lever lock (accessory to be ordered separately). It features an integrated residual current indicator and a foldable labeling plate. Connection (max): 35 mm² with insulated plug protection. The connection screws can be equipped with a sealable cover (accessory to be ordered separately).

Key specifications

Circuit breaker type
Fault current circuit breaker
Mounting type
Top-hat rail
number of poles
2
Length
72 mm

General information

Item number
21306233
Manufacturer
Gewiss
Category
Residual-current device
Manufacturer no.
GWD4032
Release date
27.6.2022

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
Mounting type
Top-hat rail
number of poles
2
Tripping characteristic
A
Rated current
40 A
Rated current
0.03 A
Rated voltage
230 V
voltage type
AC
Rated insulation voltage Ui
500 V
Residual current (rated differential current)
0.03 A
Protection type (IP code)
IP20

Origin

Country of origin
Portugal

Voluntary climate contribution

CO₂-Emission
22.03 kg
Climate contribution
CHF 0.52

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
72 mm

Package dimensions

Length
10.20 cm
Width
8.50 cm
Height
4.30 cm
Weight
192 g
