Futaba R324SBS T-FHSS Car-T- Receiver
Product details
The Futaba R324SBS is a compact and lightweight T-FHSS 2.4 GHz receiver with integrated telemetry function and diversity antenna.
It is an evolution of the proven R304SB receiver and is particularly suitable for use in RC cars and boats.
Through the S.BUS2 connection, S.BUS2 sensors can be connected, allowing for the transmission of up to 32 telemetry data sets. The integrated telemetry transmitter in the receiver sends the telemetry data from the S.BUS2 connection to the transmitter, which displays, announces, or outputs the information audibly.
Note: When using 7.4 V LiPo batteries as the receiver battery, the connected servos must also be rated for this voltage. The receiver does not have an internal voltage converter for the servo voltage!.
Frequency | 2.40 GHz |
conduits | 4 |
Operating voltage | 7.40 V |
Item number | 7644218 |
Manufacturer | Futaba |
Category | RC receivers |
Manufacturer no. | 05102643-3 |
Release date | 18.8.2017 |
Colour | Black |
Exact colour description | Black |
Material group | Plastic |
Frequency | 2.40 GHz |
conduits | 4 |
Operating voltage | 7.40 V |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1 Receiver |
Length | 2.32 cm |
Width | 3.51 cm |
Height | 1.25 cm |
Weight | 8.30 g |
Length | 8.30 cm |
Width | 6.30 cm |
Height | 3.50 cm |
Weight | 48 g |
