FrSky Receiver Archer Plus SR8 2,4Ghz

The Archer range of receivers has been extended with the new Archer Plus series.

The Archer Plus Series receivers include several new features. Firstly, an improved anti-HF interference capability can provide more solid RF performance, in addition to the existing ignition anti-interference performance. This Plus series also has two modes, ACCESS and ACCST D16, where the RF protocol is automatically matched during the binding process on the radio. With the black box function, some basic flight data (such as voltage and signal) can be easily stored.

The SR8+ receiver is a gyro-stabilised receiver with built-in 3-axis gyro as well as 3-axis accelerometer and has several flight modes (auto level, stabilisation, knife-edge flight, etc.) and configuration methods. The Archer Plus SR8+ can be used as a master receiver in a redundant solution by connecting the SBUS input to any other FrSky receiver equipped with an SBUS output. With the FBUS protocol, the Archer Plus series receivers can be easily paired with multiple telemetry devices (XACT servos, ADV sensors, etc.), facilitating the configuration of the devices.

Features:

• Improved anti-HF interference capability with more solid RF performance.

• Intelligently tuned ACCESS & ACCST D16 modes

• Supports simple black box functions

• Integrated 3-axis gyro system and 3-axis accelerometer

• Multiple flight modes and configuration options (ETHOS, LUA scripts, etc.)

• SBUS Out connector (supports 16CH / 24CH mode)

• SBUS In connector (supports signal redundancy)

• Full reception with telemetry (S.Port or FBUS)

• Anti-interference capability in ignition process

• Over-The-Air (OTA) FW update*

• External battery/unit voltage detection

(*Some functions require ACCESS and ETHOS support).
