Fronius FRON Hybrid Inverter

Fronius Inverter Symo GEN24 3.0 Plus

Manufacturer: Fronius
Designation: Inverter
Type: Symo GEN24 3.0 Plus
Max. Input Current at DC: 12.5 A
Nominal Voltage MPP: 80..800 V
Output Rated Power AC: 3000 W
Number of Independent MPPT Inputs: 2
European Efficiency: 96.7 %
With Transformer: no
With Data Logger: yes
Display: none
Ethernet: yes
Wireless: yes
Built-in Battery: no
Usable Battery Capacity: 3 kWh
Emergency Power Capability: yes
Suitable for Outdoor Installation: yes
Protection Class (IP): IP66
Weight: 15.6 kg
Width: 474 mm
Height: 530 mm
Depth: 165 mm

Fronius Inverter Symo GEN24 3.0 Plus: additional details
The Fronius Symo GEN24 Plus is the ideal hybrid inverter for private households. With many standard features, this three-phase device meets all customer needs. Standard WLAN and Ethernet connectivity, emergency power function - with the integrated PV Point (basic emergency power supply of a socket), energy management - 4 digital I/Os to increase self-consumption, Multi Flow Technology - parallel energy flows, even in emergency power situations, Dynamic Peak Manager - optimal yields even in shading conditions, SuperFlex Design - maximum freedom in PV system design, Solar.web - evaluation and analysis tool for greater transparency, a variety of open interfaces, easy integration of third-party components, Active Cooling Technology - longevity of the inverter. Max. PV Generator Power 4.5 kWpeak. Battery connection: max. input-output power 3150 W, compatible batteries: BYD Battery-Box Premium HVS/HVM, interfaces: WLAN, 2x Ethernet LAN, 6 digital inputs/outputs + 6 digital inputs for connection to round control receivers, energy management emergency shutdown (WSD), 2x RS485 for Modbus RTU SunSpec (third-party), Fronius Smart Meter, battery, Fronius Ohmpilot. EAN: 9007947330420.
