The Define 7 XL sets a new standard for what you should expect from a full tower case in terms of modularity, flexibility, and user-friendliness.
PC case design | Full tower |
Number of 3.5" drive slots (internal) | 8 x |
"Number of 5.25"" drive slots" | 2 x |
Max. length graphics card | 549 mm |
Front connectors | 1x USB 3.2 Gen2 Type-C, 2x USB 2.0, 2x USB 3.0, Audio in/out, Power button, Reset button |
PC case features | Front flap, Modular HDD cage |
Max. height CPU cooler | 185 mm |
Item number | 12766171 |
Manufacturer | Fractal |
Category | PC case |
Manufacturer no. | FD-C-DEF7X-02 |
Release date | 6.11.2021 |
Colour | Black |
Exact colour description | Light Black |
Material group | Metal, Plastic |
Material | Steel |
PC case design | Full tower |
Form factor | ATX, E-ATX, Micro ATX (mATX), Mini-ITX |
"Number of 5.25"" drive slots" | 2 x |
Number of 3.5" drive slots (internal) | 8 x |
"Number of 2.5""/3.5"" combination slots" | 6 x |
"Number of 2.5"" drive slots" | 2 x |
Number of expansion card slots | 9 x |
Max. length graphics card | 549 mm |
Max. height CPU cooler | 185 mm |
Max length of power supply | 300 mm |
PC case features | Front flap, Modular HDD cage |
Front connectors | 1x USB 3.2 Gen2 Type-C, 2x USB 2.0, 2x USB 3.0, Audio in/out, Power button, Reset button |
Number of fans | 3 x |
Number of fan slots | 11 x |
Fan location | Bottom side, Front side, Rear side, Top side |
Number of radiator mounts | 3 |
Radiator locations | Bottom side, Front side, Rear side, Top side |
Cooling properties | Water cooling possible |
LED colour | without LED |
Fans included | 2x 140mm |
Fan mount locations | 3x 140mm, 4x 120mm |
Radiator mount locations | 1x max. 480mm |
LED colour | without LED |
Fans included | 1x 140mm |
Fan mount locations | 1x 120mm, 1x 140mm |
Radiator mount locations | 1x max. 120mm |
Fans included | Optional fan |
Fan mount locations | 2x 120mm, 2x 140mm |
Radiator mount locations | 1x max. 280/240mm |
Fans included | Optional fan |
Fan mount locations | 3x 120mm, 4x 120mm |
Radiator mount locations | 1x max. 480mm |
Fan mount locations | 1x 120mm |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Installation material |
Height | 56.60 cm |
Length | 60.40 cm |
Width | 24 cm |
Weight | 16.53 kg |
Length | 80 cm |
Width | 60 cm |
Height | 30 cm |
Weight | 20 kg |
