Feller EdizioDue rotary switch
Product details
Rotary switch scheme 2/1-pole, type: insert with front plate, current: 16A, voltage: 240-400V, LED load max.: 200W, additional function: switching position 0-hand-0-automatic, changeover switch, installation depth: 31mm, colour: white, IP protection rating: IP20, EdizioDue. EDIZIOdue is much more than an attractive range of light switches and sockets. For the majority of the system solutions, it is also an overarching design philosophy for all functions. EDIZIOdue utilises the tried and tested Feller apparatus technology. The colour-neutral functional insert serves as the basis, allowing for modular flush-mounted, surface-mounted and recessed designs. Subsequent colour changes can be made quickly, as EDIZIOdue covers can be easily replaced when the appliance is connected.
Colour | White |
Switch + button type | Rotary switches |
Width | 60 mm |
Item number | 52945268 |
Manufacturer | Feller |
Category | Buttons + Switches |
Manufacturer no. | 7411-2.F.055.61 |
Release date | 13.11.2024 |
Sales rank in Category Buttons + Switches | 100 of 18710 |
Colour | White |
Exact colour description | White |
Material | Thermoplastic resin |
Switch + button type | Rotary switches |
Mounting type | Screw fastening |
Nominal voltage | 400 V |
Nominal current | 16 A |
Max. Switching capacity | 200 W |
Protection type (IP code) | IP20 |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 Piece |
Length | 60 mm |
Width | 60 mm |
Height | 49 mm |
Length | 13.70 cm |
Width | 12.90 cm |
Height | 4.90 cm |
Weight | 77 g |
