Product details
With M.2 SSDs, a new era of write and read speeds has begun. Thanks to their small size and incredible write and read speeds, the Corsair Force MP510 offers extreme performance and reliability. Designed for high-end PCs, this M.2 SSD is based on TLC 3D NAND technology and achieves random read/write speeds of up to 240,000/180,000 IOPS with the ultra-fast PCIe 3.0 x4 NVMe interface. This SSD transfers data via PCI Express, leaving traditional SATA SSDs far behind in terms of transfer rates. M.2 SSDs are installed via the M.2 socket on the motherboard. Due to their compact dimensions, they are particularly suitable for use in ultrabooks and mini-PCs, but can also be used in standard computers. In systems with NVMe support, this SSD truly shines. You benefit from high throughput, high IOPS, and low latency. Unlike the older AHCI protocol, which was developed for traditional spinning drives, NVMe prevents performance drops, offers faster transfers of large data volumes, increased boot speeds, and improved system responsiveness.
SSD type | M.2 SSD |
Interface | PCIe 3.0 |
Protocol | NVMe |
Write transfer speed | 2000 MB/s |
Read transfer speed | 3480 MB/s |
Max. random 4K write | 360000 IOPS |
Item number | 10029438 |
Manufacturer | Corsair |
Category | SSD |
Manufacturer no. | CSSD-F480GBMP510 |
Release date | 29.10.2018 |
SSD type | M.2 SSD |
Form factor | M.2 2280 |
Storage capacity | 480 GB |
Interface | PCIe 3.0 |
Protocol | NVMe |
Read transfer speed | 3480 MB/s |
Write transfer speed | 2000 MB/s |
Memory type (NAND) | TLC |
Max. random 4K write | 360000 IOPS |
Max. TBW | 800 TB |
SSD Features | AES encryption |
Power consumption (standby) | 0 W |
CO₂-Emission | |
Climate contribution |
Length | 8 cm |
Width | 2.20 cm |
Height | 0.30 cm |
Weight | 55 g |
Length | 13.20 cm |
Width | 7.90 cm |
Height | 1.50 cm |
Weight | 26 g |
