Chieftec Power supply, BDF-600S, 600W

600 W
66Ratings
Delivered between Thu, 3.7. and Tue, 8.7.

Product details

With the current PROTON series, CHIEFTEC enters the innovative Double Forward technology. The foundation for this is special, high-quality capacitors. These Double Forward power supplies achieve the best possible efficiency as a result. The advantages are clear: they save energy while providing much higher efficiency and solid performance, which in turn ensures greater longevity of the installed components. The performance of the PROTON power supplies is certified with 80PLUS BRONZE, thus meeting all requirements to comply with all ENERGY STAR 5.0 and higher standards.

Key Features

Energy
Total Power 600 W
AC Input Voltage 115 - 230 V
AC Input Frequency 50 - 60 Hz
Power Factor 0.9
Power Factor Correction (PFC) Active
Combined Output Current (+3.3V) 103 W
Combined Output Current (+5V) 103 W
Max Output Current (+3.3V) 18 A
Max Output Current (+12V).

Key specifications

Form factor
ATX
80 PLUS certificate
Bronze
Modularity
Permanently installed
Internal connection options
15-pin S-ATA (6x), 24-pin ATX power connector (1x), 4-pin CPU (1x), 4-pin Molex (3x), 6+2-pin PCI Express (2x), 8-pin EPS (1x)
Item number
6412302

General information

Manufacturer
Chieftec
Category
Power Supply PC
Manufacturer no.
BDF-600S
Release date
30.7.2017
Sales rank in Category Power Supply PC
199 of 2524
External links
Manufacturer's site (de)
May include power adapter
Yes

Colour

Colour
Black
Exact colour description
Black

Power supply properties

Form factor
ATX
Efficiency
85 %
80 PLUS certificate
Bronze
Modularity
Permanently installed

Power supply connectors

Internal connection options
15-pin S-ATA (6x), 24-pin ATX power connector (1x), 4-pin CPU (1x), 4-pin Molex (3x), 6+2-pin PCI Express (2x), 8-pin EPS (1x)

Cooling properties

Fan location
Top side
Cooling method
Active cooling
Number of fans
1 x
Fan diameter
120 mm

Safety

Power protection features
EIA, OCP, OLP, OPP, OTP, OVP, SCP

Power supply

Power
600 W

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Instruction manual

Product dimensions

Length
14 cm
Width
15 cm
Height
8.70 cm

Package dimensions

Length
25 cm
Width
18 cm
Height
11 cm
Weight
1.95 kg
