Chieftec 400W EON Series ZPU-400S

Main Features

Energy
Total Power 400 W
AC Input Voltage 200 - 240 V
AC Input Frequency 50 Hz
Input Current 3 A
Maximum Input Current (at 220V) 3 A
Power Factor 0.9
Power Factor Correction Filter (PFC) Active
Combined Current (-12V) 4.8 W
Combined Current (+5Vsb) 12.5 W
Max Output Current (+3.3V) 20 A
Max Output Current (+12V1) 30 A
Max Output Current (+5V) 20 A
Max Output Current (-12V) 0.4 A
Max Output Current (+5Vsb) 2.5 A
Energy Protection Features: Short Circuit, Over Voltage and Inrush, Over Voltage Protection

Connections and Interfaces
Motherboard Connector 20+4 pin ATX
Number of Molex Connectors 4pin 2
Power Cable Length to Motherboard 55 cm
Number of SATA Power Connectors 4
SATA Power Cable Length 550, 600 mm
Peripheral (Molex) Power Cable Length 150, 450 mm
EPS Power Connector (4+4 pin) Yes
Number of PCI Express Power Connectors 6+2pin 1
CPU Connector (4+4 pin) Yes
ATX Power Connector (20+4 pin) Yes
Cable Type Non-Modular

Performance
Purpose PC / Server
Power Supply Unit (PSU) Form Factor ATX
80 Plus Certification 80 PLUS
Supported Motherboard Form Factors ATX
ATX Version 2.3

Design
Product Color Black
Fan Diameter 12 cm
Power Switch Yes

Weight and Dimensions
Width 150 mm
Depth 140 mm
Height 86 mm
Weight 1.15 kg

Packaging Data
Package Weight 1.4 kg
Packaging Type Box

Technical Details
Sustainability Certifications CB, CE, EAC, ErP, RoHS
Warranty Period 2 Year(s).
