Busch-Jaeger LR/S 2.16.1 LR/S 2.16.1 Light controller/switching dimming actuator
Dimming actuatorDelivered between Thu, 11.6. and Thu, 25.6.
free shipping
Product details
Device for switching and dimming two independent lighting groups with electronic ballasts (0-10 V control input). In conjunction with the light sensor LF/U 2.1, the device can be used as a two-channel light controller for constant light regulation. KNX.
Actuator type | Dimming actuator |
Mounting type | Top-hat rail |
Smart Home Protocol | KNX |
Items per sales unit | 1x |
Item number | 23989330 |
Manufacturer | Busch-Jaeger |
Category | Actuator |
Manufacturer no. | 2CDG110087R0011 |
Release date | 11.1.2023 |
Actuator type | Dimming actuator |
Max. Switching capacity | 2300 W |
rated current | 16 A |
Number of switching outputs | 2x |
Mounting type | Top-hat rail |
Protection type (IP code) | IP20 |
Smart home | Compatible |
Smart Home Protocol | KNX |
Requires Smart Home Hub | No |
Country of origin | Germany |
CO₂ emissions | 16.89 kg |
Climate contribution | CHF 0.40 |
Items per sales unit | 1x |
Length | 10 mm |
Specifications may include unverified machine translations.
