Busch-Jaeger Blind switch

Busch-Jaeger blind switch 2712 SLW-54

Manufacturer: Busch-Jaeger
Designation: Blind switch
Labelling sheet type: 2712 SLW-54
Assembly: Basic element with complete housing
Design: Other
Number of poles: 2
Operation type: Key
Electrical and mechanical interlocking: No
Mechanically operable: Yes
Electronically operable: No
Mounting type: Surface-mounted
Material: Plastic
Material quality: Thermoplastic
Halogen-free: Yes
Surface protection: Untreated
Surface finish: Matt
Mounting type: Mounting with screw
Colour: Alpine white
RAL number (similar): 9010
Transparent: No
Text field/inscription area: Yes
Suitable for protection class (IP): IP44
Rated current: 10 A
Rated voltage: 250 V
Number of modules (for modular design): 1

Further details: For profile half cylinder. Key-operated latching switch. Key can only be removed in centre position. With labelling field (57.8 x 9.8 mm). IP 44 only in conjunction with corresponding locking cylinders. Key cannot be removed in end position. Suitable labelling software available.
