Block Transformer PCB 25VA 2x15V
Delivered between Fri, 6.6. and Wed, 11.6.
Only 1 item in stock at supplier
Only 1 item in stock at supplier
Product details
Secondary rated voltage = 15V ac
Nominal power = 25VA
Primary rated voltage = 230V ac
Number of outputs = 2
Length = 81.2mm
Width = 49.2mm
Depth = 55mm
Dimensions = 81.2 x 49.2 x 55mm
Weight = 610g
Mounting type = through hole mounting
Temperature max = +40°C
EN 61 558 IEC 61558 ENEC, UL approval. To comply with VDE 0550, UL506, the secondary windings of all transformers with 2 24 V outputs should not be connected in series... PCB mounted, 230 Vac primary, VC/VCM series. One and two secondary windings for series or parallel connection Molded with resin under vacuum to UL94-V0 Low capacitance between turns Low noise 100 % electrical and breakdown testing Extra mounting points for secure PCB mounting (25 VA and 36 VA).
input voltage | 230 V |
Output voltage | 15 V |
transformer type | PCB transformer |
Electric current | 0.83 A |
Power | 25 W |
Item number | 9910183 |
Manufacturer | Block |
Category | Transformer |
Manufacturer no. | VCM 25/2/15 |
Release date | 16.10.2018 |
External links |
transformer type | PCB transformer |
input voltage | 230 V |
Output voltage | 15 V |
Electric current | 0.83 A |
Power | 25 W |
CO₂-Emission | |
Climate contribution |
Weight | 610 g |
