Product details
The OC socket from ASUS is designed for peak performance. It uses additional pins to connect the hidden features of the Haswell E architecture with a special circuit from ASUS. In conjunction with our customized UEFI BIOS, higher DDR4 memory frequencies, lower latencies, and improved stability are achieved when overclocking – even for extreme use cases with liquid nitrogen cooling. The OC socket is fully compatible with the LGA 2011-3 socket for Haswell-E architecture CPUs, making it the ideal combination of overclocking capabilities and compatibility.
Processor family | Core i7 4th Gen |
Memory type | DDR4-RAM |
Number of memory modules (RAM) | 8 x |
Wireless transmission | Bluetooth |
Item number | 2753939 |
Manufacturer | ASUS |
Category | Motherboards |
Manufacturer no. | 90MB0JF0-M0EAY0 |
Release date | 30.8.2014 |
External links |
Form factor | ATX |
Socket | LGA 2011-v3 |
Chipset | Intel X99 |
Operating system compatibility | Windows |
BIOS type | UEFI AMI |
Wireless transmission | Bluetooth |
Wi-Fi standard | Wi-Fi 1 / 802.11b, Wi-Fi 2 / 802.11a, Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n, Wi-Fi 5 / 802.11ac |
Processor family | Core i7 4th Gen |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 8 x |
Max. memory (RAM) | 64 GB |
Memory chip | DDR4-2400, DDR4-2666, DDR4-2800 |
Max. RAM OC | 3200 MHz |
Supported memory speed | 2133 MHz |
Memory type | DDR4-RAM |
RAM buffer | Unbuffered |
Video connections | Thunderbolt (1x) |
Multi-GPU technology | AMD 3-Way CrossFireX, AMD Quad-GPU CrossFireX, NVIDIA Quad SLI, NVIDIA Tri-SLI |
Network connections | RJ45 (2x) |
Ethernet controller brand | Intel |
Ethernet controller | Intel I211-AT, Intel I218V |
Max. port speed | 1 Gbit/s |
Chip | Realtek ALC1150 |
Audio channel | 8.1 Channel |
Expansion slot | PCI Express x1 (1x) |
Number of fan connector | 6 |
Power connectors | 24-pin ATX, 8-pin ATX 12V |
CO₂-Emission | |
Climate contribution |
Scope of delivery | S-ATA cable, User manual |
Length | 302 mm |
Width | 244 mm |
Height | 244 mm |
