B650-Plus WiFi
The ASUS Prime series motherboards are expertly designed to harness the full potential of AMD Ryzen 9000, 8000, and 7000 series processors. With a robust power design, comprehensive cooling solutions, and intelligent tuning options, the Prime B650-Plus WiFi offers users and PC DIY builders a variety of performance optimizations through intuitive software and firmware features. This platform delivers the performance and connectivity required for advanced AI PC applications.
Processor family | AMD 7000 Series |
Memory type | DDR5 RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | M.2 PCIe (2x), S-ATA III (4x) |
Wireless transmission | Bluetooth, Wi-Fi |
Mainboard features | Serial header, Thunderbolt header, Trusted Platform Module |
Item number | 52239649 |
Manufacturer | ASUS |
Category | Motherboards |
Manufacturer no. | 90MB1KP0-M0EAY0 |
Release date | 5.2.2025 |
Sales rank in Category Motherboards | 126 of 969 |
Form factor | ATX |
Socket | AM5 |
Chipset | AMD B650 |
Mainboard features | Serial header, Thunderbolt header, Trusted Platform Module |
Operating system compatibility | Windows 10 |
BIOS type | UEFI AMI |
Wireless transmission | Bluetooth, Wi-Fi |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Processor family | AMD 7000 Series |
Memory form factor | DIMM |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 192 GB |
Memory chip | DDR5 SDRAM |
Max. RAM OC | 7600 MHz |
Supported memory speed | 4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz, 6000 MHz, 6200 MHz, 6400 MHz, 6600 MHz, 7000 MHz, 7600 MHz, 7800 MHz |
Memory type | DDR5 RAM |
RAM buffer | Unbuffered |
Video connections | DisplayPort (1x), HDMI (1x) |
Network connections | RJ45 2.5 Gigabit Ethernet (1x) |
Max. port speed | 2.50 Gbit/s |
Audio channel | 7.1 Channel |
RAID configuration | 0, 1, 10 |
Internal connection options | M.2 PCIe (2x), S-ATA III (4x) |
Expansion slot | PCI Express x1 (2x), PCI Express x16 (Gen 4) (1x) |
PCI express version (max.) | 5 |
Number of fan connector | 3 |
USB ports | USB-A |
Exact USB ports | USB-A 2.0 (2x), USB-A 3.2 Gen 2 (3x) |
Country of origin | China |
Manufacturer commitment | RE100, SBTi |
Manufacturer compensation | According to RE100, the manufacturer ASUS fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Aerial, Sata Cables |
Length | 244 mm |
Width | 305 mm |
Height | 244 mm |
Weight | 1350 g |
Length | 34.70 cm |
Width | 27.30 cm |
Height | 7.10 cm |
Weight | 1.65 kg |
